• Test and troubleshoot telephone, data and coax wiring
• NETcat Pro 2 New Features:- Gigabit device capability detection (still detects 10baseT and 100baseT too), - Cable type, velocity of propagation library, user editable, - Powerover Ethernet (PoE) detection, - Memo pad
• Detect split pairs, short circuits, broken and crossed wires
• Step TDR technology shows length to open or short of all pairs
• Test shielded twisted-pair(STP), unshielded twisted-pair (UTP) & coaxial cables
• Test patch cords and remote jacks
• Touch-screen control, included stylus slots into main unit
• Large icons ensure easy use with your finger too
• Large 3 IN (76mm) backlit high-contrast (user adjustable) monochrome display is highly visible in dark or brightly lit areas
• Remote test and ID unit stores in base of main unit
• Can identify up to 8 remote test ID units (7 extra available in NC-510 accessory kit along with carrying case)
• Tone generator with four selectable precision frequency tones, compatible with Greenlee advanced digital signal processing probes
• Operates on single 9V battery with low battery indication

• Accessory : NC-510 NETcat Pro 2 AccessoryKit W/Carry Case
• Accuracy to OpenShort : Plus Or Minus 4 PCT Or 2.000 FT (0.600 MR) Whichever Is Greater
• Application : To Test And Troubleshoot Telephone, Data And Coax Wiring
• Backlight : White LED
• Battery : 9 V Alkaline Battery (PP3)
• Buttons : LCD Touch-Screen, Single Momentary Contact Push Button
• Depth : 6.700 IN
• Display LCD : Dot Pixels: 128 X 128 Dots
• Interface Connections : RJ45 Shielded Jacks F-Type Threaded Female Coaxial Connectors
• Length : 3.300 IN
• Remote Identifier : 2000.000 FT
• Resolution : 1.000 FT (0.300 MR)
• Storage/Operating Temperature : -20 To 70 DEG C0 - 50 DEG C
• Sub Brand : NETcat
• TDR Calibration :
• User Selectable Based On A Known Cable Length
• 40 PCT To 100 PCT In StepsOf 1 PCT
• TDR Range : 0 - 2000 FT
• Type : 2 Digital VDV Wiring
• Weight : 0.450 LB (200.000 GM)
• Width : 1.400 IN
• Wiremap : 358.000 FT (100.000 MR)

• Netcat Pro 2 Main Unit WithStylus
• Removable Remote Jack And Patch Lead Test And Id Unit
• Twisted-Pair (Modular Rj45), Coax (F) And Alligator ClipTest Cords
• 9V Alkaline Battery

Features:

• Test and troubleshoot telephone, data and coax wiring
• NETcat Pro 2 New Features:- Gigabit device capability detection (still detects 10baseT and 100baseT too), - Cable type, velocity of propagation library, user editable, - Powerover Ethernet (PoE) detection, - Memo pad
• Detect split pairs, short circuits, broken and crossed wires
• Step TDR technology shows length to open or short of all pairs
• Test shielded twisted-pair(STP), unshielded twisted-pair (UTP) & coaxial cables
• Test patch cords and remote jacks
• Touch-screen control, included stylus slots into main unit
• Large icons ensure easy use with your finger too
• Large 3 IN (76mm) backlit high-contrast (user adjustable) monochrome display is highly visible in dark or brightly lit areas
• Remote test and ID unit stores in base of main unit
• Can identify up to 8 remote test ID units (7 extra available in NC-510 accessory kit along with carrying case)
• Tone generator with four selectable precision frequency tones, compatible with Greenlee advanced digital signal processing probes
• Operates on single 9V battery with low battery indication

Specifications:

• Accessory : NC-510 NETcat Pro 2 AccessoryKit W/Carry Case
• Accuracy to OpenShort : Plus Or Minus 4 PCT Or 2.000 FT (0.600 MR) Whichever Is Greater
• Application : To Test And Troubleshoot Telephone, Data And Coax Wiring
• Backlight : White LED
• Battery : 9 V Alkaline Battery (PP3)
• Buttons : LCD Touch-Screen, Single Momentary Contact Push Button
• Depth : 6.700 IN
• Display LCD : Dot Pixels: 128 X 128 Dots
• Interface Connections : RJ45 Shielded Jacks F-Type Threaded Female Coaxial Connectors
• Length : 3.300 IN
• Remote Identifier : 2000.000 FT
• Resolution : 1.000 FT (0.300 MR)
• Storage/Operating Temperature : -20 To 70 DEG C0 - 50 DEG C
• Sub Brand : NETcat
• TDR Calibration :
• User Selectable Based On A Known Cable Length
• 40 PCT To 100 PCT In StepsOf 1 PCT
• TDR Range : 0 - 2000 FT
• Type : 2 Digital VDV Wiring
• Weight : 0.450 LB (200.000 GM)
• Width : 1.400 IN
• Wiremap : 358.000 FT (100.000 MR)

Includes:

• Netcat Pro 2 Main Unit WithStylus
• Removable Remote Jack And Patch Lead Test And Id Unit
• Twisted-Pair (Modular Rj45), Coax (F) And Alligator ClipTest Cords
• 9V Alkaline Battery
