Product Details
＋
FBS LCD 12/4M, 12VDC Pluggable Surge Protection Device for IT Systems, LPZ 0A-2 of higher, 10kA, for Balanced and Unbalanced systems
Specifications
| Telebahn part number | FBS LCD 12/4M |
| Nominal Voltage | 12VDC |
| No of Poles | 4 |
| Category IEC / EN / VDE | Type 2 |
| Location of use | Communication/Signal Lines |
| Protection modes | L1 /L1-, L2 /L2- , for |
| Additional Remote Contacts | NO |
| Protective element | MOV |
| No Fault/Fault Indication | N/A |
| Surge discharge rating | Per pole 10kA (8/20uS)10KA) Max, 20kA (8/20uS)2.5KA) Nominal |
| Internal protection and safety | Thermal disconnector in each MOV |
| Weight | 120g |
| Standards | IEC 61643-21; EN 61643.21; GB 18802.21 |
